RCCN EPDM Tubing
Material:EPDM rubber Features:aging resistant environment,under ground,lower temperature resistant Operate temperature:-50℃ to 200℃ Color:black |
|
|
Suitable cable outer dia. |
Thickness after shrinking |
Length/PCS mm |
EPDM20 | Φ20 | 9-17 | 3.1±0.2 | 120-180 |
EPDM25 | Φ25 | 10-20 | 3.7±0.2 | 180-280 |
EPDM32 | Φ32 | 12-28 | 3.9±0.2 | 230-300 |
EPDM35 | Φ35 | 13-31 | 3.9±0.2 | 230-280 |
EPDM40 | Φ40 | 17.5-33 | 4.1±0.2 | 150-350 |
EPDM53 | Φ53 | 25-50 | 4.5±0.2 | 150-230 |
EPDM70 | Φ70 | 28-65 | 5.0±0.2 | 150-300 |
EPDM104 | Φ104 | 43-94 | 5.5±0.2 | 230 |
Tags: RCCN EPDM Tubing
