RCCN TFL Teflon Tubing



Material:PTFE
Features:rot resistant、acid resistant、oil resistant,high voltage
resistant(26kV/mm)
Operate temperature:-80℃ to 260℃；
Color:transparent
Item No.


Metric
inner dia.
 Inner D
mm		 Std.Pkg.
M
TFL Inner dia.-Outer dia.
TFL0.30-0.80 TFL0.30-0.70 TFL0.30-0.64 Φ0.30 0.30±0.10 305
TFL0.38-0.88 TFL0.38-0.78 TFL0.38-0.72 Φ0.38 0.38±0.10 305
TFL0.46-0.96 TFL0.46-0.86 TFL0.46-0.80 Φ0.46 0.46±0.10 305
TFL0.56-1.16 TFL0.56-1.06 TFL0.56-0.90 Φ0.56 0.56±0.10 305
TFL0.66-1.26 TFL0.66-1.16 TFL0.66-1.00 Φ0.66 0.66±0.10 305
TFL0.71-1.31 TFL0.71-1.21 TFL0.71-1.05 Φ0.71 0.71±0.10 305
TFL0.81-1.41 TFL0.81-1.31 TFL0.81-1.15 Φ0.81 0.81±0.10 305
TFL0.86-1.66 TFL0.86-1.46 TFL0.86-1.20 Φ0.86 0.86±0.10 305
TFL0.96-1.76 TFL0.96-1.56 TFL0.96-1.30 Φ0.96 0.96±0.20 200
TFL1.07-1.87 TFL1.07-1.67 TFL1.07-1.41 Φ1.07 1.07±0.20 200
TFL1.19-1.99 TFL1.19-1.79 TFL1.19-1.53 Φ1.19 1.19±0.20 200
TFL1.34-2.14 TFL1.34-1.94 TFL1.34-1.68 Φ1.34 1.34±0.20 153
TFL1.50-2.30 TFL1.50-2.10 TFL1.50-1.84 Φ1.50 1.50±0.20 153
TFL1.68-2.48 TFL1.68-2.28 TFL1.68-2.08 Φ1.68 1.68±0.20 100
TFL1.93-2.73 TFL1.93-2.53 TFL1.93-2.33 Φ1.93 1.93±0.20 100
TFL2.16-2.96 TFL2.16-2.76 TFL2.16-2.56 Φ2.16 2.16±0.25 100
TFL2.41-3.21 TFL2.41-3.01 TFL2.41-2.81 Φ2.41 2.41±0.25 150
TFL2.69-3.49 TFL2.69-3.29 TFL2.69-3.09 Φ2.69 2.69±0.25 150
TFL3.00-4.00 TFL3.00-3.80 TFL3.00-3.40 Φ3.00 3.00±0.25 150
TFL3.38-4.38 TFL3.38-4.18 TFL3.38-3.78 Φ3.38 3.38±0.25 100
TFL3.76-4.76 TFL3.76-4.56 TFL3.76-4.16 Φ3.76 3.76±0.25 100
TFL4.22-5.22 TFL4.22-5.02 TFL4.22-4.80 Φ4.22 4.22±0.25 100
TFL4.72-5.72 TFL4.72-5.52 TFL4.72-5.32 Φ4.72 4.72±0.25 50
TFL5.28-6.28 TFL5.28-6.08 TFL5.28-5.88 Φ5.28 5.28±0.30 1M/Branch or 50M/Roll
TFL5.94-6.94 TFL5.94-6.74 TFL5.94-6.54 Φ5.94 5.94±0.30 1M/Branch
TFL6.68-7.68 TFL6.68-7.48 TFL6.68-7.28 Φ6.68 6.68±0.30 1M/Branch
TFL7.46-8.46 TFL7.46-8.26 TFL7.46-8.06 Φ7.46 7.46±0.30 1M/Branch
TFL8.38-9.38 TFL8.38-9.18 TFL8.38-8.98 Φ8.38 8.38±0.30 1M/Branch
