RCCN SR Strain Relief Bushings



Material:UL approved NYLON 66(black),
fireproof 94V-2
Use:according to the pictures above

Item No.
shape
ULWires
Approx.wiresize
Mounting Hole

Part L.
D.
Max. Chassis
Thickness
F.
Packing
A B
SR-F21 FLAT SPT-1#18 2.3X4.5或2.8X5.3 9.5 8.7 10.3 0.5-1.6
100pcs
SR-F23 SPT-1#18 2.3X4.5或2.8X5.3 9.5 8.7 10.3 1.8-3.2
SR-F31 SPT-1#18 3.0X5.6 11.0 9.9 10.3 1.0-1.6
SR-F32 SPT-1#18 3.0X5.6 11.0 9.9 10.3 1.9-2.5
SR-F41 SPT-2#18 3.0X7.1或3.8X7.6 12.7 11.8 10.3 0.5-1.6
SR-F42 SPT-2#18 3.0X7.1或3.8X7.6 12.7 11.8 10.3 1.8-2.5
SR-F51 SPT-3#18 5X10.4 14.3 12.9 15.2 0.5-1.6
SR-F53 SPT-3#18 5X10.4 14.3 12.9 15.2 1.8-3.5
SR-F83 Wire 3C 2mm2 6X15.2 21.6 21.3 20.4 2.0-3.4
SR-5R1 ROUND SVI,SVT3C#18 6.2ø ~7.4ø 12.8 11.5 11.0 0.5-1.6
SR-5R2 SVI,SVT3C#18 6.2ø ~7.4ø 13.0 11.5 11.0 1.8-2.5
SR-6W2 SVI3C#18 7.6ø 12.8 11.8 11.0 1.8-2.3
SR-6P1 SJC 3C # 18 7.4ø~8.2ø 15.9 14.0 14.8 0.5-1.6
SR-6P3 SJC 3C # 18 7.4ø~8.2ø 15.9 14.0 14.8 1.9-3.2
SR-6R1 SJ,SJT,3C # 16 8.2ø~9.2ø 15.9 14.0 14.8 0.5-1.6
SR-6R3 SJ,SJT,3C # 16 8.2ø~9.2ø 15.9 14.0 14.8 1.9-3.2
SR-7R1 SJT,3C # 14 9.2ø~10.5ø或11ø 19.9 17.0 19.0 0.5-1.6
SR-7R3 SJT,3C # 14 9.2ø~10.5ø或11ø 19.7 17.0 19.0 1.9-3.2
SR-8R3 SJT,3C # 12 12ø~15.2ø 21.6 21.3 20.6 1.9-3.2
SR-9R1 # 18 20-30pcs 11ø~15ø 15 19 17.5 0.5-1.6
SR-9R7 SJT,3C # 10 15.2ø~16.3ø 28.0/30.2 25.5 25.2 1.0-3.2
17.5ø
