RCCN Feed-Through Terminals JY1-2
|
Material: nylon 66, fireproof 94-V0, |
| Item No.
|
Suitable Wireway mm2 |
Current A Voltage V |
Suitable terminals |
Inside screw |
Packing |
| JY1-2 | 4-6 | 41/660 | 8-4 | M4 | 50 |
| JY1-3 | 4-6 | 41/660 | 8-4 | M4 | 50 |
RCCN Din Rails
| Material:high quality and strength cold rolled steel with electroplate EN50022 Product standard: EN50022 Color: yellow plated nickle,silver plated zinc Operated temperature:-40°C standing heat to 100°C Use way: fixed on the panel then installed with electric parts Features: perfect design,with huge pressure,exactly dia., rust resistant Special length or special hole come with MOQ., Rohs approved products are available. TS-35/7.5/1/1M/R Environment-friendly goods’ part no.:TS-35/7.5/1/1M/ROHS |
| Item No. Outer width/Outer height/ Thickness/Length |
Material | Length per pcs |
Packing/ carton |
| TS-35/7.5 Series | |||
| TS-35/7.5/1.0/1M | Color zinc steel | 1M | 50M |
| TS-35/7.5/1.0/1M-ROHS | ROHS silver zinc plated steel | 1M | 50M |
| TS-35/7.5/1.0/2M | Color zinc steel | 2M | 100M |
| TS-35/7.5/1.0/2M-ROHS | ROHS silver zinc plated steel | 2M | 100M |
| TS-35/15 Series | |||
| TS-35/15/1.5/1M | Color zinc steel | 1M | 30M |
| TS-35/15/1.5/1M-ROHS | ROHS silver zinc plated steel | 1M | 30M |
| TS-35/15/1.5/2M | Color zinc steel | 2M | 60M |
| TS-35/15/1.5/2M-ROHS | ROHS silver zinc plated steel | 2M | 60M |
| LSC-35/7.5/1.1 Series | |||
| LSC-35/7.5/1.1/1M | ROHS Aluminum metal | 1M | 100M |
| LSC-35/7.5/1.1/2M | ROHS Aluminum metal | 2M | 100M |
| LSC-35/7.5/1.1/1M-No bottom | ROHS Aluminum metal | 1M | 100M |
| LSC-35/7.5/1.1/2M-No bottom | ROHS Aluminum metal | 2M | 100M |
| LS-35/7.5/1.5 Series | |||
| LS-35/7.5/1.5/1M | ROHS Aluminum metal | 1M | 100M |
| LS-35/7.5/1.5/2M | ROHS Aluminum metal | 2M | 100M |
| LS-35/7.5/1.5/1M-No bottom | ROHS Aluminum metal | 1M | 100M |
| LS-35/7.5/1.5/2M-No bottom | ROHS Aluminum metal | 2M | 100M |
