RCCN Feed-Through Terminals JHY1
Note: L type is slot opening in the terminal, using of arraning |
Item No.
|
Suitable Wireway mm2 |
Current A Voltage V |
Suitable terminals |
Inside screw |
Packing |
JHY1-9 | 0.5-1.5 | 9/660 | 1.25-3 | M3 | 50 |
JHY1-9L | 0.5-1.5 | 9/660 | 1.25-3 | M3 | 50 |
JHY1-16 | 0.5-1.5 | 16/660 | 1.25-3 | M3 | 50 |
JHY1-16L | 0.5-1.5 | 16/660 | 1.25-3 | M3 | 50 |
JHY1-25 | 1.5-2.5 | 25/660 | 2-4 | M4 | 50 |
JHY1-25L | 1.5-2.5 | 25/660 | 2-4 | M4 | 50 |
JHY1-32 | 1.5-4 | 32/660 | 2-4 | M4 | 50 |
JHY1-32L | 1.5-4 | 32/660 | 2-4 | M4 | 50 |
JHY1-63 | 4-16 | 63/660 | 8-5 | M5 | 50 |
JHY1-63L | 4-16 | 63/660 | 8-5 | M5 | 50 |
JHY1-100 | 6-25 | 100/660 | 22-6 | M6 | 50 |
JHY1-100L | 6-25 | 100/660 | 22-6 | M6 | 50 |
JHY1-150 | 25-50 | 150/660 | 38-8 | M8 | 20 |
JHY1-150L | 25-50 | 150/660 | 38-8 | M8 | 20 |
JHY1-250 | 35-100 | 250/660 | 80-12 | M12 | 10 |
JHY1-250L | 35-100 | 150/660 | 80-12 | M12 | 10 |
JHY1-400 | 35-150 | 400/660 | 150-12 | M12 | 10 |
JHY1-400L | 35-150 | 400/660 | 150-12 | M12 | 10 |
RCCN Din Rails
Material:high quality and strength cold rolled steel with electroplate EN50022 Product standard: EN50022 Color: yellow plated nickle,silver plated zinc Operated temperature:-40°C standing heat to 100°C Use way: fixed on the panel then installed with electric parts Features: perfect design,with huge pressure,exactly dia., rust resistant Special length or special hole come with MOQ., Rohs approved products are available. TS-35/7.5/1/1M/R Environment-friendly goods’ part no.:TS-35/7.5/1/1M/ROHS |
Item No. Outer width/Outer height/ Thickness/Length |
Material | Length per pcs |
Packing/ carton |
TS-35/7.5 Series | |||
TS-35/7.5/1.0/1M | Color zinc steel | 1M | 50M |
TS-35/7.5/1.0/1M-ROHS | ROHS silver zinc plated steel | 1M | 50M |
TS-35/7.5/1.0/2M | Color zinc steel | 2M | 100M |
TS-35/7.5/1.0/2M-ROHS | ROHS silver zinc plated steel | 2M | 100M |
TS-35/15 Series | |||
TS-35/15/1.5/1M | Color zinc steel | 1M | 30M |
TS-35/15/1.5/1M-ROHS | ROHS silver zinc plated steel | 1M | 30M |
TS-35/15/1.5/2M | Color zinc steel | 2M | 60M |
TS-35/15/1.5/2M-ROHS | ROHS silver zinc plated steel | 2M | 60M |
LSC-35/7.5/1.1 Series | |||
LSC-35/7.5/1.1/1M | ROHS Aluminum metal | 1M | 100M |
LSC-35/7.5/1.1/2M | ROHS Aluminum metal | 2M | 100M |
LSC-35/7.5/1.1/1M-No bottom | ROHS Aluminum metal | 1M | 100M |
LSC-35/7.5/1.1/2M-No bottom | ROHS Aluminum metal | 2M | 100M |
LS-35/7.5/1.5 Series | |||
LS-35/7.5/1.5/1M | ROHS Aluminum metal | 1M | 100M |
LS-35/7.5/1.5/2M | ROHS Aluminum metal | 2M | 100M |
LS-35/7.5/1.5/1M-No bottom | ROHS Aluminum metal | 1M | 100M |
LS-35/7.5/1.5/2M-No bottom | ROHS Aluminum metal | 2M | 100M |
