RCCN Feed-Through Terminals JH9
Note:ZG part no. is used for fixing clapboard, Z is used |
Item No.
|
Suitable Wireway mm2 |
Current A Voltage V |
Suitable terminals |
Inside screw |
Packing |
JH9-1.5 | 0.75-1.5 | 17.5/660 | 1.25-3 | M3 | 50 |
JH9-1.5ZG | - | - | - | - | 50 |
JH9-2.5 | 1-2.5 | 24/660 | 2-4 | M4 | 50 |
JH9-2.5Z | 1-2.5 | 24/660 | 2-4 | M4 | 50 |
JH9-2.5ZG | - | - | - | - | 50 |
JH9-6 | 2.5-6 | 41/660 | 5.5-5 | M5 | 50 |
JH9-6Z | 2.5-6 | 41/660 | 5.5-5 | M5 | 50 |
JH9-6ZG | - | - | - | - | 50 |
JH9-10 | 4-10 | 57/660 | 8-6 | M6 | 50 |
JH9-10Z | 4-10 | 57/660 | 8-6 | M6 | 50 |
JH9-10ZG | - | - | - | - | 50 |
JH9-25 | 10-25 | 101/660 | 22-6 | M6 | 50 |
JH9-25Z | 10-25 | 101/660 | 22-6 | M6 | 50 |
JH9-25ZG | - | - | - | - | 50 |
RCCN Din Rails
Material:high quality and strength cold rolled steel with electroplate EN50022 Product standard: EN50022 Color: yellow plated nickle,silver plated zinc Operated temperature:-40°C standing heat to 100°C Use way: fixed on the panel then installed with electric parts Features: perfect design,with huge pressure,exactly dia., rust resistant Special length or special hole come with MOQ., Rohs approved products are available. TS-35/7.5/1/1M/R Environment-friendly goods’ part no.:TS-35/7.5/1/1M/ROHS |
Item No. Outer width/Outer height/ Thickness/Length |
Material | Length per pcs |
Packing/ carton |
TS-35/7.5 Series | |||
TS-35/7.5/1.0/1M | Color zinc steel | 1M | 50M |
TS-35/7.5/1.0/1M-ROHS | ROHS silver zinc plated steel | 1M | 50M |
TS-35/7.5/1.0/2M | Color zinc steel | 2M | 100M |
TS-35/7.5/1.0/2M-ROHS | ROHS silver zinc plated steel | 2M | 100M |
TS-35/15 Series | |||
TS-35/15/1.5/1M | Color zinc steel | 1M | 30M |
TS-35/15/1.5/1M-ROHS | ROHS silver zinc plated steel | 1M | 30M |
TS-35/15/1.5/2M | Color zinc steel | 2M | 60M |
TS-35/15/1.5/2M-ROHS | ROHS silver zinc plated steel | 2M | 60M |
LSC-35/7.5/1.1 Series | |||
LSC-35/7.5/1.1/1M | ROHS Aluminum metal | 1M | 100M |
LSC-35/7.5/1.1/2M | ROHS Aluminum metal | 2M | 100M |
LSC-35/7.5/1.1/1M-No bottom | ROHS Aluminum metal | 1M | 100M |
LSC-35/7.5/1.1/2M-No bottom | ROHS Aluminum metal | 2M | 100M |
LS-35/7.5/1.5 Series | |||
LS-35/7.5/1.5/1M | ROHS Aluminum metal | 1M | 100M |
LS-35/7.5/1.5/2M | ROHS Aluminum metal | 2M | 100M |
LS-35/7.5/1.5/1M-No bottom | ROHS Aluminum metal | 1M | 100M |
LS-35/7.5/1.5/2M-No bottom | ROHS Aluminum metal | 2M | 100M |
