RCCN PW Plastic Washer
Material:PC(natural),PA66(natural),PP(white),fireproof 94V-2 Usage:PC board,panel and to fix others. Characteristics:light,insulated. Marks:PW-3C is made of PC,PW-5N are made of NYLON66,PW-6PP is PP |
|
screw M |
mm |
mm |
C mm |
|
PW-M2 | M2 | 5 | 2.1 | 0.5 | 1000PCS |
PW-M3 | M3 | 8 | 3.2 | 0.8 | |
PW-M4 | M4 | 9 | 4.3 | 0.8 | |
PW-M5 | M5 | 11 | 5.3 | 1.0 | |
PW-M6 | M6 | 12 | 6.4 | 1.7 | 500PCS |
PW-M8 | M8 | 15 | 8.5 | 1.7 | |
PW-M10 | M10 | 20 | 10.5 | 1.7 | |
PW-M12 | M12 | 23.5 | 12.5 | 1.8 | |
PW-M16 | M16 | 31 | 16.5 | 2.4 | |
PW-M20 | M20 | 34 | 20.5 | 2.4 | |
PW-12 | 22 | 12 | 1.5 | ||
PW-14 | 24 | 14 | 1.5 | ||
PW-12.7 | 23.8 | 12.7 | 1.6 | ||
PW-15.8 | 25.4 | 15.8 | 2.4 | ||
PW-19 | 27 | 19 | 2.4 |
