RCCN PGB Nylon Cable Gland
 |
| Thread:DIN STANDARD,NPT,G Material:A.C.E.F made of Rohs approved NYLON66,B.D made of NBR Certificate:UL/CUL:E348185,CE, SGS,REACH,EX Fireproof:UL94V-2。 Operate temperature:-50°C to 150°C。 Protect class:IP68。 Color:light gray(RAL7035),black(RAL9005) |
| Item No. | Thread | CableRangeΦ | ThreadO.D.D1 | PanelMountingHole | ThreadLengthL1 | SpannersizeA&F | Std.PkgPcs | |
| Black | White | |||||||
| PG | 100PCS | |||||||
| PGB7S-06B | PGB7S-06G | PG7 | 2-6 | 12.5 | 12.5-12.8 | 8 | 18/19 | |
| PGB7-07B | PGB7-07G | PG7 | 4-8 | 12.5 | 12.5-12.8 | 8 | 18/19 | 50PCS |
| PGB9-08B | PGB9-08G | PG9 | 4-8 | 15.2 | 15.2-15.8 | 10 | 22/20 | |
| PGB11-10B | PGB11-10G | PG11 | 5-10 | 18.6 | 18.6-18.9 | 10 | 22/22 | |
| PGB13.5-12B | PGB13.5-12G | PG13.5 | 6-12.5 | 20.4 | 20.4-20.7 | 10 | 24/22 | |
| PGB16-14B | PGB16-14G | PG16 | 8.5-14 | 22.5 | 22.5-22.8 | 10.8 | 33/25 | |
| PGB19-14B | PGB19-14G | PG19 | 6-14 | 23.5 | 24.1-24.5 | 11 | 33/25 | |
| PGB21-18B | PGB21-18G | PG21 | 12.5-18 | 28.3 | 28.3-28.7 | 12 | 33/27 | |
| PGB25-20B | PGB25-20G | PG25 | 14-20 | 30.1 | 30.1-30.3 | 13 | 33/27 | 20PCS |
| PGB29-25B | PGB29-25G | PG29 | 17-25 | 37.0 | 37.0-37.4 | 12 | 33/33 | 10PCS |
| PGB36-32B | PGB36-32G | PG36 | 24-32 | 47.0 | 47.0-47.4 | 14 | 41/42 | |
| PGB42-41B | PGB42-41G | PG42 | 30-41 | 54.0 | 54.0-54.4 | 15 | 45/42 | |
| PGB48-46B | PGB48-46G | PG48 | 35-46 | 59.3 | 59.3-59.7 | 15.5 | 50/52 | |
