RCCN BN Butt Splice Nylon Insulated













Maximum current: 26-22 A.W.G: 9A 22-16 A.W.G: 19A 16-14 A.W.G: 27A 12-10 A.W.G: 48A

Maximum pressure: 105 ℃ 600V insulating sheath material: Nylon

Item No. Current square(mm)

Joint material

Conductor cross section



A.W.G

COLOR
L
BN-0.5 20.0 2.0 1.3

Red copper

26-22 A.W.G  0.2-0.5mm² Yellow
BN 1.25 27.3 3.2 1.7

Red copper

22 – 16 A.W.G   0.5 – 1.5 mm² Red
BN 2 27.3 3.8 2.3

Red copper

16 – 14 A.W.G   1.5 – 2.5 mm² Blue
BN 5.5 27.3 5.3 3.4

Red copper

14 – 10 A.W.G   4 – 6 mm² Yellow
